One of the simplest techniques for indicating liquid level
is by means of a direct reading device with which the level
can be seen visually. A common method of providing such visual
indication is by installing direct reading gages in the vessel
itself. These direct reading gages are placed at different
locations or points to indicate the liquid height. More often,
separately mounted gage glasses are used to provide a continuous
indication of level over a certain vertical distance on the
vessel.
Standard construction (for the Series
32 Gage) includes a solid one-piece chamber machined from
bar, steel covers, tempered glass, alloy steel bolts and
nuts. Select reflex
gage (prismatic) Style Glass or transparent
glass gage. Recessed gasket
seats prevent gasket movement. Series 32 gages are
available in a variety of materials to meet specific corrosive
conditions. Transparent Model Shown See
Glass Example
Accessories available include: illuminators (both Incandescent and Fiber
Optic), non-frosting extensions,
support brackets and insulation jackets.
|
| |
|
All standard chamber materials (carbon
steel and stainless steel) are NACE MR-01-75 acceptable materials.
|
| |
| Specifications
for Series 32 Gages |
- Section Lengths: Gage sections are available in nine standard glass sizes. Longer sizes are constructed with multiple vision slots in a continuous solid bar chamber.
- Connections: Standard connections are at top and bottom and are 1/2" or 3/4" NPT female. Optional connections are available, such as socket weld, flanged or close hook-up (side/side).
- Liquid Chamber: Machined bar stock. The gasket seat is recessed to allow lateral support and facilitate positioning.
- Covers: Forged carbon steel is standard. Optional materials are available such as 316SS. The cushion gasket seat is recessed.
- Bolts & Nuts: Alloy steel is standard, A193 B7 and A194 2H. Optional materials are available. All steel fasteners are "black oxide" treated to prevent rust.
- Glass: Tempered Borosilicate is used to 600° F (316° C). Aluminosilicate is used to 800° F (427° C). Transparent glass may be protected from corrosive media with mica or Neoflon CTFE shields.
- Gaskets: Standard gaskets are precision die cut in proprietary Jerguson dies.
- Finish: All steel parts are finish coated prior to assembly. Stainless steel is not coated.
NOTE: It is recommended that all gages be installed with Jerguson gage valves having safety ballchecks which help provide protection against physical injury and loss of product if glass breakage should occur. |
| |
| Specify Gage Assemblies by the Figures given below: |
| Fig. 1 |
Fig. 2 |
Fig. 3 |
Fig. 4 |
Fig. 5 |
Fig. 6 |
Fig. 7 Offset Inside |
Fig. 8 Offset Outside |
 |
 |
 |
 |
 |
 |
 |
 |
| Valves |
Valves |
Valves |
Valves |
Valves |
Valves |
Valves |
Valves |
| 63, 143, 73BL & 93 |
64, 144, 74BL & 94 |
66, 146 & 76BL |
67, 147 & 77BL |
63, 143, 73BL & 93 |
64, 144, 74BL & 94 |
146, 147, 66, 67, 76BL & 77BL |
146, 147, 66, 67, 76BL & 77BL |
|
|
|
| |
| Support
Files / Links For Series 32 Gages |
| Dimensional
Information for Series 32 Gages |
| Click
Here For Examples of Transparent and Reflex Glass |
| |
|
| |
| Series 32 Models and Dimensions |
Sect. Size |
Visible Range |
Overal Length |
Reflex, R-32 Weight |
Transp., T-32 Weight |
|
in |
mm |
in |
mm |
Ibs |
Kgs |
Ibs |
Kgs |
| Single Section Models |
11 |
3-3/4 |
95 |
5-1/4 |
133 |
8 |
3.6 |
10 |
4.5 |
12 |
4-3/4 |
121 |
6-1/4 |
159 |
9 |
4.1 |
14 |
6.4 |
13 |
5-3/4 |
146 |
7-1/4 |
184 |
11 |
5.0 |
17 |
7.7 |
14 |
6-3/4 |
171 |
8-1/4 |
210 |
12 |
5.5 |
19 |
8.6 |
15 |
7-7/8 |
200 |
9-3/8 |
238 |
14 |
6.4 |
21 |
9.5 |
16 |
9-1/8 |
232 |
10-5/8 |
270 |
16 |
7.3 |
24 |
10.9 |
17 |
10-1/4 |
260 |
11-3/4 |
298 |
18 |
8.2 |
27 |
12.3 |
18 |
11-7/8 |
302 |
13-3/8 |
340 |
20 |
9.1 |
30 |
13.6 |
19 |
12-5/8 |
321 |
14-1/8 |
359 |
21 |
9.5 |
32 |
14.5 |
| Two-Section Models |
23 |
13 |
330 |
14-1/2 |
368 |
22 |
10.0 |
33 |
15.0. |
24 |
15 |
381 |
16-1/2 |
419 |
25 |
11.4 |
38 |
17.3 |
25 |
17-1/4 |
438 |
18-3/4 |
476 |
28 |
12.7 |
43 |
19.5 |
26 |
19-3/4 |
502 |
21-1/4 |
540 |
32 |
14.5 |
49 |
22.3 |
27 |
22 |
559 |
23-1/2 |
597 |
35 |
15.9 |
54 |
24.5 |
28 |
25-1/4 |
641 |
26-3/4 |
679 |
40 |
18.2 |
61 |
27.7 |
29 |
26-3/4 |
679 |
28-1/4 |
718 |
43 |
19.5 |
64 |
29.1 |
| Three-Section Models |
36 |
30-3/8 |
772 |
31-7/8 |
810 |
48 |
21.8 |
73 |
33.2 |
37 |
33-3/4 |
857 |
35-1/4 |
895 |
53 |
24.1 |
80 |
36.4 |
38 |
38-5/8 |
981 |
40-1/8 |
1019 |
60 |
27.3 |
92 |
41.8 |
39 |
40-7/8 |
1038 |
42-3/8 |
1076 |
64 |
29.1 |
97 |
44.1 |
| Four-Section Models |
47 |
45-1/2 |
1156 |
47 |
1194 |
71 |
32.3 |
107 |
48.6 |
48 |
52 |
1321 |
53-1/2 |
1359 |
80 |
36.4 |
122 |
55.5 |
49 |
55 |
1397 |
56-1/2 |
1435 |
85 |
38.6 |
129 |
58.6 |
| Five-Section Models |
57 |
57-1/4 |
1454 |
58-3/4 |
1492 |
88 |
40.0 |
134 |
60.9 |
58 |
65-3/8 |
1661 |
66-7/8 |
1699 |
100 |
45.5 |
152 |
69.1 |
59 |
69-1/8 |
1756 |
70-5/8 |
1794 |
106 |
48.2 |
161 |
73.2 |
| Six-Section Models |
68 |
78-3/4 |
2000 |
80-1/4 |
2038 |
120 |
54.5 |
187 |
85.0 |
69 |
83-1/4 |
2115 |
84-3/4 |
2153 |
127 |
57.7 |
196 |
89.1 |
| Seven-Section Models |
78 |
92-1/8 |
2340 |
93-5/8 |
2378 |
140 |
63.6 |
221 |
100.5 |
79 |
97-3/8 |
2473 |
98-7/8 |
2511 |
148 |
67.3 |
230 |
104.5 |
| Eight-Section Models |
88 |
105-1/2 |
2680 |
107 |
2718 |
160 |
72.7 |
254 |
115.5 |
89 |
111-1/2 |
2832 |
113 |
2870 |
169 |
76.8 |
265 |
120.5 |
|
|
|
|
| |
