RCM Flowmeter Standard and Optional Construction

Do you have any questions that I can help you with?

Specifications	Standard	Optional
Housing	Polycarbonate-UV Stabilized	None
Body	Bronze	Monel - 316SS
Bellows	Bronze	Monel - 316SS - Inconel
Seals	Buna-N	Viton - EPR - Teflon
Crystal	Polycarbonate	None
Gear Movement	Bronze	316SS
Accuracy	± 3% F.S.	± 3% F.S.
Repeatability	± 1% F.S.	± 1% F.S.
Pressure - Maximum	180psig	400psig
Pressure - Minimum	10psig	10psig
Temperature - Maximum	212° F	350° F
Temperature - Minimum	-30° F	-80° F
