Jerguson Model RS-2 Point Level Switches

Point level switches are actuated by the Magnicator II float.

  • Easy installation - clamp to Magnicator II chamber.
  • Latches to maintain position as the float passes.
  • Field adjustable.
  • No contact with process.

The Jerguson Magnicator II point level switches are fully adjustable and non-invasive. Switch points can be changed easily without any interruption to the visual indication or process.  The bias magnet design latches the switch maintaining the contact after the level continues to rise or fall.  All switches are mercury free and environmentally safe.

  • Hermetically Sealed Bi-Stable Latching Reed Switch.
  • Continuous 1 Amp, Maximum 2 Amp Current Load @ 130 VAC/VDC
  • NEMA 7 for NEC Class 1, Div 1, Groups B, C & D
  • EEX dIIC T6
  • USL, CNL approved for service in Class I, Groups B, C, & D
  • Directly control low-amp equipment, or as an input to controllers or DCS systems.
  • Available with either SPDT or DPDT action.

This simple reed switch device can be used to directly control low-amp equipment, or as an input to user supplied controllers or DCS systems. Available with either SPDT or DPDT action.

  • Maximum Voltage: 130 VAC/VDC
  • Maximum Current: 2.0 amps
  • Nominal Current: 1.0 amp
  • Maximum Power: 30 Watts
  • Deadband: 0.375"
  • Maximum Temperature (Process): Temperatures above 300°F require special mounting and insulation options.
  • Minimum Temperature: -40°F
  • Enclosure: NEC Class 1, Div 1, Groups B, C & D NEMA 4X
  • Contacts: SPDT or DPDT
  • Conduit Connection: 3/4" NPT
